Trade Name:Deserialiser
Brand:ADI
Particular Year:24+
Package:TQFN-48
Delivery Date:New and Original
Stock: 25000pcs
The MAX9296AGTM/V deserializer converts single or dual serial inputs to MIPI CSI-2 outputs. The device operates in either GMSL1 or GMSL2 mode. The MAX9296A also sends and receives side-channel data, enabling full-duplex transmission of forward path video and bidirectional control data over low-cost 50Ω coax or 100Ω STP cables to meet the GMSL2 or GMSL1 channel specification.
The MAX9296AGTM/V operates over the automotive temperature range of -40°C to +105°C and is AEC-Q100 qualified.
Benefits and Features
● Dual Four-Lane MIPI CSI-2 v1.3 Output Ports
• Aggregation and Replication Functions
• 16-Channel Virtual Channel Support
• Supports RAW8/10/12/14/16/20, RGB565/666/888, YUV422 8-/10-bit, User-Defined, and Generic Long Packet Data Types
● Advanced MIPI D-PHY v1.2 Transmitters
• 80Mbps to 2.0Gbps per Lane
• Polarity Flip and Data-Lane Reassignment
● Flexible Input Configuration
• Independent Serial Inputs Accept Video with Different Timing and Resolution
• Support for Mixed GMSL2 and GMSL1 Inputs
● Multiple GMSL2 Data Rates for System and Power Flexibility
• 3Gbps or 6Gbps Forward Link Rates
• 187.5Mbps Reverse Link Rate
● Backward-Compatible GMSL1 Mode
● Full-Duplex Capability Over a Single Wire
● Ideal for High-Definition Camera Applications
• Supports 2MP+/4MP at 60fps and 8MP at 40fps
● ASIL-Relevant Functional Safety Features (GMSL2)
• ASIL-B Compliant in GMSL2 Mode
• 16-Bit CRC Protection of Side-Channel Data (I2C, UART, SPI, GPIO) with Retransmission Upon Error Detection
• Optional 32-Bit Video-Line CRC
• Video Watermark Insertion and Detection
● Forward and Reverse Channel PRBS for BER Testing of Serial Link
Applications
● High-Definition (2MP+/4MP 60fps) Advanced Driver
Assistance Systems (ADAS)
• Surround View Systems (SVS)
• Rear View Cameras (RVC)
• Camera Monitoring Systems (CMS)
• Driver Monitoring Systems (DMS)
● 8MP 40fps Forward Vision Cameras (FVC)
● Satellite Lidar and Radar Sensors
● Gesture Cameras
● ECU-to-ECU Links
