The OPA862IDTKR is a 12.6V, low-noise, single-ended to differential, high-input impedance amplifier.

The OPA862 single-end to differential analog-to-digital converter (ADC) driver has a high input impedance and can be directly connected to the sensor. With a gain set to 2V/V, the device consumes only 3.1mA of static current to achieve an output reference noise density of 8.3nV/√Hz.

Specifications

Amplifier type: General purpose

Circuit number: 2

Output type: Full swing

Voltage swing rate: 140V/µs

Gain bandwidth product: 400 MHz

Current-input bias: 5 nA

Voltage-input compensation: 50 µV

Current - Power supply: 3.1mA (x2 channel)

Current - Output/channel: 60 mA

Voltage - span (min) : 3 V

Voltage - span (Max.) : 12.6V

Operating temperature: -40°C ~ 125°C (TA)

Mounting type: Surface mount type

Package/housing: 8-WFDFN bare pad

Supplier Package: 8-WSON (3x3)

Applications

• 16-bit and 18-bit ADC drivers

• Memory and LCD tester

• Data Acquisition (DAQ)

• Test and measurement

• Transresistance Amplifier (TIA)

• Class D audio amplifier driver

• Piezoelectric sensor interface

• Medical instruments
