MAX77785EWJ is a high-performance high-input fast charger. The ICs can operate as a reverse boost converter without an additional inductor, allowing the battery to share its power through the charging port, and offer programmable output voltage from 4.505V to 10.805V.

Features

High-Efficiency Single-Cell Switching Charger

90% Buck Efficiency at 4A, 15V Input

+26V Absolute Maximum Input Voltage Rating

4.7V to 18.2V Input Operating Voltage Range

Reverse Boost with Programmable Output Voltage Options up to 10.805V

Dedicated Boost enable input

Integrated Battery True-Disconnect FET

RDSON = 7.7mΩ

Programmable Discharge Current Limit up to 10A

Shipping Mode and Low Battery Leakage Current

1.3MHz Switching Frequency with 1μH Inductor

Disconnect Input (DISQBAT)

Safety

Battery Temperature Sensing and Charge Safety Timer

JEITA Guideline Compliant

Thermal Regulation and Thermal Shutdown

System Voltage OVLO/UVLO

USB Switch with BC1.2 Detection

Spread Spectrum for Noise-Sensitive Applications

Charge Status Output for LED

Push-Button Input for Exiting from Ship Mode

Programmable Unplug Detection Output

Dedicated Input for Suspend Mode (SUSPND)

I2C Interface

Applications

Gaming Devices

VR Applications

mPOS

Tablet PCs
