The ISL9238, a rise and fall VDC battery charger with SMBus interface and USB OTG, is a rise and fall output voltage Direct current (NVDC) charger. The ISL9238C provides NVDC charging, system bus conditioning and protection for tablets, ultrabooks, laptops, mobile power supplies and any USB-C interface platform. Advanced Renesas R3™ technology provides high light-load efficiency and fast transient response.

In charging mode, the ISL9238C accepts input power from a variety of DC power sources, such as traditional AC/DC charger adapters, USB PD ports, and travel adapters, and uses up to four lithium batteries to safely charge the battery pack. As an NVDC topological charger, the ISL9238C can also adjust the system output to a narrow DC range for a stable system bus voltage.

peculiarity

• Elevating NVDC charger for 2 -, 3 - or 4-cell lithium batteries

• Input voltage range: 3.9V to 23.4V (no dead zone)

• System output voltage: 2.4V to 18.304V

• Autonomous charging option (automatic charging)

• Direct mode

• System power monitor PSYS output, IMVP compliant

• Switching frequency up to 1MHz

• Adapter current and battery current monitor (Amon/BMON)

• PROCHOT# open leakage output, compatible with IMVP

• Allows trickle charging of depleted batteries

• Ideal diode control in Turbo mode

• Battery reverse buck, boost, and buck - boost operations

• Two-stage adapter current limits are available

• 100% only 2-FET step-down mode option

• Battery delivery mode options

• SMBus is compatible with auto-increment I2C

• 4mm X 4mm 32 LD TQFN package
