The BQ25792RQMR is a fully integrated switch-mode buck/boost charger designed for 1-4 cell lithium-ion and lithium-polymer batteries. The integration includes four switch MOSFETs (Q1, Q2, Q3, Q4), input and charge current detection circuits, a battery FET (QBAT), and loop compensation for the buck/boost converter. It uses NVDC power path management to regulate the system voltage to a level slightly above the battery voltage but does not drop below the configurable minimum system voltage. When system power exceeds the input source rating, the battery boost mode supports the system without overloading the input source. The BQ25792RQMR supports the full input and output (OTG) voltage range for USB Type-C™ and USB Power Delivery (USB-PD) applications.

BQ25792RQMR Features

• High power density, highly integrated buck/boost charger for 1–4 cells, supporting any USB PD 3.0 profile

– Integrated four switch MOSFETs and BATFET

– Integrated input and charging current detection

• Efficient

– 750kHz or 1.5MHz switching frequency

– 5A charging current with 10mA resolution

• Efficiency up to 96.5%: charging a 16V battery from a 20V input at 3A current

• Supports wide input sources

– Wide input operating voltage range from 3.6V to 24V, with an absolute maximum voltage rating of 30V

– Maximum power tracking, input voltage dynamic power management (VINDPM) up to 22V, input current dynamic power management (IINDPM) up to 3.3A

– Detects USB BC1.2, SDP, CDP, DCP, HVDCP, and non-standard adapters

• Dual input power multiplexer controller for source selection (optional)

• Narrow Voltage DC (NVDC) power path management

• Powering USB ports from the battery (USB OTG)

– OTG output voltage from 2.8V to 22V with 10mV resolution, supporting USB-PD PPS

– OTG output current regulation up to 3.32A with 40mA resolution

• Flexible autonomous and I2C modes for excellent system performance

• Integrated 16-bit ADC for voltage, current, and temperature monitoring

• Low battery static current

– 21μA when operating on battery power only

– 600nA in charger shutdown mode

• High precision

– 2S-4S battery charging voltage regulation range of +0.65% to -0.85%

– Charging current regulation range of ±5%

– Input current regulation range of ±5%

• Safety

– Thermal regulation and thermal shutdown

– Input/battery OVP and OCP

– Converter MOSFET OCP

– Charging safety timer

• Packaging

– 29-pin, 4mm × 4mm QFN

BQ25792RQMR Applications

• Video doorbells, smart home control

• Data concentrators, lawn mowing robots, vacuum cleaning robots

• Asset tracking, mobile POS

• Multi-parameter patient monitors, electrocardiogram (ECG), ultrasound smart probes
