The IXYH10N170C device uses proprietary thin-wafer XPT technology and the most advanced IGBT process design, featuring low thermal resistance, low tail current, low energy loss and high-speed switching capability. Applications include pulse circuits, laser and X-ray generators, high voltage power supplies, high voltage test equipment, capacitor discharge circuits, AC switches.

Product attribute

IGBT type: -

Voltage-emitter breakdown (Max) : 1700 V

Current-collector (Ic) (Max.) : 36 A

Current-collector pulse (Icm) : 84 A

Vce(on) (Max.) for different Vge and Ic: 3.8V @ 15V, 10A

Power - Max: 280 W

Switching power: 1.4mJ (on), 700µJ (off)

Input type: Standard

Grid charge: 46 nC

Td (On/off) value at 25°C: 14ns/130ns

Test conditions: 850V, 10A, 10Ohm, 15V

Reverse recovery time (trr) : 17 ns

Operating temperature: -55°C ~ 175°C (TJ)

Installation type: Through hole

Package/housing: TO-247-3

Supplier Device Package: TO-247 (IXYH)

Basic product number: IXYH10
