STPS30H60CGY ST's automotive power Schottky diodes combine low dropout characteristics with negligible or zero recovery. With a voltage range of 30 to 170V and a current range of 1 to 80A, they meet the needs of all applications from OR-ing and 48V converters to battery chargers and welding equipment. The devices are available in a wide range of packages, including through-hole and surface mount industry standard form factors, as well as PowerFLAT™ packages. These power Schottky diodes are designed to meet the stringent requirements of the automotive industry and are AEC-Q101 certified.

Product Attributes

Diode Configuration: 1 pair common cathode

Technology: Schottky

Voltage - DC reverse (Vr) (max): 60 V

Current - Average Rectification (Io) (per diode): 15A

Voltage - Forward (Vf) at Different If: 660 mV @ 15 A

Speed: Fast Recovery = < 500ns, > 200mA (Io)

Current - reverse leakage at varying Vr: 60 µA @ 60 V

Operating Temperature - Junction: -40°C ~ 175°C

Rating: Automotive Grade

Qualification: AEC-Q101

Mounting Type: Surface Mount

Package/Housing: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB

Supplier Device Package: D2PAK
