Commodity Model:VIPER318HDTR

Trade Name:AC DC Converter

Brand:ST

Particular Year:21+

Package:SO-16

Delivery Date:New and Original

Stock: 2500pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ST
Model
VIPER318HDTR
Package
SO-16
Describe
Offline converter Boost, buck, buck-boost, flyback topology 132kHz 16-SO

Product Description

The VIPER318HDTR is a high-voltage converter that intelligently integrates an 800 V avalanche-type power MOSFET and PWM current-mode control. The 800 V breakdown voltage enables a wider input voltage range while reducing the size of the DRAIN buffer circuit. This IC meets the most stringent energy efficiency standards due to its extremely low power consumption and operates in pulse frequency modulation mode under light load conditions. Overvoltage protection (OVP) and undervoltage protection (UVP) are provided on the OVP and UVP pins, respectively, with independently adjustable thresholds. UVP can also function as a disable input for the entire switching power supply (SMPS) and has ultra-low residual input power consumption. Integrated high-voltage startup, detection FET, error amplifier, and frequency jitter oscillator enable the design of a complete application with minimal component count. Supports flyback, buck, and buck-boost topologies.


VIPER318HDTR Features

Built-in 800V MOSFET, supporting a 132kHz PWM switching frequency, optimised for EMI performance.

Integrated high-voltage start-up circuit, eliminating the need for an auxiliary winding and reducing BOM costs.

Standby power consumption as low as 20mW (265V input), compliant with global energy efficiency standards.

Wide VCC supply voltage range of 4.5V to 30V, suitable for various input conditions.

Applicable to flyback (isolated/non-isolated), buck, boost, and buck-boost topologies.

Overload, overvoltage, overheat, and short-circuit protection enhance system reliability.

Soft-start control reduces power-on surge.

Operating temperature range: -40°C to +150°C (TJ), suitable for harsh environments.


VIPER318HDTR Applications

• Low-power switching power supplies for home appliances, home automation, industrial, consumer electronics, and lighting applications

• Low-power adapters


VIPER318HDTR Parameters

Manufacturer: STMicroelectronics

Package: 16-SOIC (3.90mm width)

Input voltage range: Supports mains rectified input (wide voltage adaptation)

Switching frequency: 132kHz (fixed)

Output power: 1W (typical)

Protection features: Overload, overvoltage, overheat, short circuit

Operating temperature: -40°C to +150°C (TJ)
