STPS41H100CG is a dual common-cathode Schottky diode array packaged in a D2PAK (TO-263-3) package, suitable for high-frequency switching power supplies, DC-DC converters, and power management circuits. This device features low forward voltage drop, high current carrying capacity, and excellent switching performance, significantly reducing power loss and improving system efficiency.

STPS41H100CG Key Features

Forward Voltage (Vf): 800mV @ 20A (typical), reducing conduction losses.

Reverse Repetitive Peak Voltage (VRRM): 100V, suitable for medium to high-voltage applications.

Average Rectification Current (Io): 20A per diode, total device current 40A.

Peak surge current (Ifsm): 220A (non-repetitive), enhancing surge resistance.

Reverse recovery time (trr): <500ns (@200mA Io), suitable for high-frequency applications.

Low reverse leakage current (Ir): 10μA @ 100V (maximum), improving system stability.

Operating temperature range: -65°C to +175°C, suitable for harsh environments.

Compliant with RoHS standards, lead-free environmentally friendly design.

Compact packaging: D2PAK (TO-263-3) surface mount packaging, dimensions 10.4mm × 9.35mm × 4.6mm.

STPS41H100CG Product Attributes

Product Type:    Schottky Diode and Rectifier

Mounting Style:    SMD/SMT

Package/Case:    D2PAK-3 (TO-263-3)

Configuration:    Dual Anode Common Cathode

Technology:    Si

If - Forward Current:    40 A

Vrrm - Repetitive Reverse Voltage:    100 V

Vf - Forward Voltage:    900 mV

Ifsm - Forward Surge Current:    220 A

Ir - Reverse Current:    10 uA

Minimum Operating Temperature:    -65°C

Maximum Operating Temperature:    +175°C

STPS41H100CG Typical Applications

Switching Power Supplies (SMPS): High-frequency rectification, reducing switching losses.

DC-DC Converters: Improving conversion efficiency, suitable for industrial power modules.

Motor Drives & Inverters: High-frequency freewheeling diodes, reducing reverse recovery losses.

Server/Communication Equipment Power Supplies: High current density design, optimising thermal performance.
