Trade Name:LT3093IDD
Data Manual:LT3093IDD.pdf
Brand:ADI
Particular Year:23+
Package:12-WFDFN
Delivery Date:New and Original
Stock: 1000pcs
The LT3093IDD is a high-performance low dropout negative linear regulator featuring ADI's ultra-low noise and ultra-high PSRR architecture to power noise-sensitive applications. The devices can be easily paralleled to further reduce noise, increase output current and dissipate heat on the PCB. Delivering 200mA at a typical 190mV dropout, with an operating quiescent current of 2.35mA nominal down to 3µA at shutdown, the device's wide output voltage range (0V to -19.5V) error amplifier operates in unity gain to provide virtually indistinguishable output voltages.
Product Characteristics
Output Configuration: Negative
Output Type: Adjustable
Number of Regulators: 1 1
Voltage - Input (maximum): -20 В -20 В
Voltage - output (minimum/fixed): -20 В 0 В
Voltage - output (max.): -19,5 В
Voltage drop (max.): 0.3 V, 200 mA
Current - Output: 200 mA
Current - Static (Iq): 10 µA
Current - Supply (max): 80 mA 80 mA
PSRR: 73 dB (1 MHz)
Control characteristics: current limit, turn-on
Protection characteristics: overcurrent, overheat, short circuit
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package/case: 12-WFDFN (with open area)
Delivery incl. 12-WFDFN (3x3)
Applications
● RF and precision power supplies
● Ultra-low noise instruments
● High-speed/high-precision data converters
● Medical applications: diagnostics and imaging
● Post regulators for switching power supplies
