The ISO7741QDWWRQ1 provides high EMI and low radiation at low power consumption while isolating CMOS or LVCMOS digital I/O. The logic input and output buffers of each isolated channel are isolated by a double-capacitance silicon dioxide (SiO 2) insulated gate. The devices have enable pins that can be used to place the respective outputs in a high impedance state and reduce power consumption in multi-master drive applications.

Product Characteristics

Technology Capacitively coupled

Type: General Purpose General Purpose

Isolated power supply None

Number of channels 4

Inputs - Side 1/Side 2: 3/1

Channel Type Unidirectional

Voltage - Isolated 5700Vrms

Common Mode Transient Immunity (min): 85kV/µs 85kV/µs

Data Rate 100Mbps

Propagation Delay tpLH / tpHL (max): 16ns, 16ns 16ns, 16ns

Pulse width distortion (max): 4.9ns 4.9ns

Rise/Fall Time (typical) 2.4ns, 2.4ns

Voltage - Supply 2.25V ~ 5.5V

Ratings Automotive Grade

Certification: AEC-Q100 AEC-Q100

Operating Temperature: -40°C ~ 125°C

Mounting Type Surface Mount

Package/Shell: 16-SOIC (0.551 inch, 14.00 mm wide)

Supplier Device Package: 16-SOIC

Applications

● Hybrid, electric, and powertrain systems (EV/HEV)

● Battery Management Systems (BMS)

● On-board chargers

● Traction inverters

● DC/DC converters

● Inverters and motor controls
