The TPS79650DCQR TPS796 series of low dropout (LDO) low power linear regulators feature high power supply rejection ratio (PSRR), ultra-low noise, fast start-up, and excellent line and load transient response in small form factor, 3 x 3 VSON, SOT223-6 and TO-263 packages. Each device in this series has a small 1µF ceramic capacitor at the output and is very stable.

Specification

Product type: Low dropout voltage regulator

Mounting Style: SMD/SMT

Package / Case: SOT-223-6

Output voltage: 5 V

Output current: 1 A

Number of Outputs: 1 Output

Polarity: Positive

Static current: 265 uA

Input voltage (min): 2.7 V

Input voltage (max): 5.5 V

Output type: Fixed

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C

Return voltage: 220 mV

Series: TPS79650

Return voltage - max: 300 mV

Height: 1.6 mm

Ib - input bias current: 265 uA

Length: 6.5 mm

Line regulation: 0.05 % / V

Load regulation: 5 mV

Humidity sensitivity: Yes

Operating supply current: 260 uA

Operating temperature range: - 4

Factory packed quantity: 2500

Voltage regulation accuracy: 3 %

Width: 3.5 mm

Applications

- RF: VCOs, receivers, ADCs

- Audio

- Bluetooth, WLAN

- Cellular and cordless phones

- Handheld organisers, PDAs
