The TLE8444SL is a protected Quad-Half-Bridge-IC targeted towards automotive and industrial motion control applications. It is a monolithic die based on Infineon’s smart mixed technology SPT which combines bipolar and CMOS control circuitry with DMOS power devices.

Features

• 4 Half-Bridge Power Outputs (1.3Ω RDS(ON)MAX @ Tj =150°C)

• Minimum Overcurrent Shutdown at 0.9A

• Simple parallel interface control of Half-Bridge Outputs

• Inverted and Non-inverted Inputs to minimize number of microcontroller connections

• Very low current consumption in sleep mode (max. 5µA)

• Error Flag Diagnosis

• Open Load Diagnosis in ON-state for all outputs

• Outputs protected against overcurrent

• Over temperature protection with hysteresis

• Over and Under voltage lockout

• 3.3V / 5V compatible inputs with hysteresis

• No crossover current

• Internal freewheeling diodes

• Thermally enhanced package (fused leads)

• Green Product (RoHS compliant)

• AEC Qualified

Target Applications:

• Unipolar or Bipolar Loads

• Stepper Motors (e.g. Idle Speed Control)

• DC brush Motors
