The LT8364EMSE is a current mode DC/DC converter with a 60V, 4A switch and an input range operating from 2.8V to 60V. With a unique single-feedback pin architecture, the device can be configured in boost, SEPIC or negative output configurations. Burst-mode operation consumes static current as low as 9μA to maintain high efficiency at very low output current conditions while keeping typical output ripple below 15mV.

specification

Function: Boost, boost/buck

Output configuration: positive

Topology: Boost, SEPIC

Output type: Adjustable

Output number: 1

Voltage - input (min) : 2.8V

Voltage - input (Max) : 60V

Voltage - output (min/fixed) : 1.6V

Voltage - output (Max) : 60V (switch)

Current - Output: 4A (switch)

Frequency-switch: 300kHz ~ 2MHz

Synchronous rectifier: Yes

Operating temperature: -40°C ~ 125°C (TJ)

Mounting type: Surface mount type

Package/Housing: 16-TFSOP (0.118", 3.00mm wide) 12 leads, bare pad

Supplier device package: 16-SOP-EP

Basic product number: LT8364
