A wide supply input range of 4.2V to 60V enables control of many common DC bus voltages. The devices can withstand and protect against loads from positive and negative supplies up to ±60V. The integrated back-to-back FETs provide reverse current blocking, making the device ideal for systems that require output voltage to be maintained during power failures and undervoltage conditions. The TPS26602 internal reliable protection control module and high withstand voltage values help to simplify system design for surge protection.

Features

- 4.2V to 60V operating voltage, 62V absolute maximum

- Integrated reverse input polarity protection down to -60V

- No additional components required

- Integrated back-to-back MOSFET with a total RON of 150mΩ

- Adjustable current limit from 0.1A to 2.23A (±5% accuracy at 1A)

- Functional safety available

- Documentation available to help create functionally safe system designs

- Provides load protection during surges with minimal external components (IEC 61000-4-5)

- IMON current indicator output (±8.5% accuracy)

- Low quiescent current, 300µA at operation and 20µA at shutdown

- Adjustable UVLO, OVP cut-off, output swing rate control

- Reverse current blocking

- 38V fixed overvoltage clamp (TPS26602 only)

- Available in easy-to-use 16-pin HTSSOP and 24-pin VQFN packages

- Optional current-limited fault response options (auto-retry, latching, circuit breaker mode)

- UL 2367 listed

- File number 169910

- RILIM ≥ 5.36kΩ (2.35A maximum current)

- UL60950 - Safety during single point fault testing

- Open/short circuit ILIM detection

Applications

- Programmable logic controllers

- Distributed control systems (DCS)

- Control and automation

- Redundant power supplies ORing

- Industrial grade surge protection
