Service Telephone:86-755-83294757
Trade Name:ADPD188BI-ACEZRL
Data Manual:ADPD188BI-ACEZRL.pdf
Brand:ADI
Particular Year:23+
Package:24-LGA-CAV
Delivery Date:New and Original
Stock: 1000pcs
The ADPD188BI-ACEZRL is a complete smoke photometric detection system with dual wavelength optics. The module integrates a high-efficiency photometric front-end, two light-emitting diodes (LEDs) and two photodiodes (PDs). Light travels directly from the LEDs to the photodiodes without first entering the smoke detection chamber. The ASIC front end includes a control block, a 14-bit analogue-to-digital converter (ADC) and three flexible, independently configurable LED drivers. The control circuitry includes flexible LED signalling and synchronised detection.
Features
● 3.8 mm × 5.0 mm × 0.9 mm module with integrated optics assembly
● 1 blue LED, 1 IR LED and 2 photodiodes
● 2 external inputs for other sensors (e.g. carbon monoxide (CO) and temperature)
● (CO) and temperature)
● Three 370 mA LED drivers
● 20-bit burst accumulator, 20 bits per sample cycle
● On-board sample-to-sample accumulator with up to 27 bits per data reading
● SNR optimised for signal-limited conditions
● I2C or SPI communication
Applications
● Smoke detection
Model
Brand
Package
Quantity
Describe
ST
6-UFBGA
1000
RF Attenuators 2dB ~ 22dB 10 GHz ~ 60 GHz 50 Ohms 250mW 16-VFLGA Exposed Pad
ADI
24-LGA-CAV
1000
Optical Sensor Environment 470nm, 850nm I²C, SPI 24-VFLGA Exposed Pad
A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.
A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.
A: at present, our self-employed brands TI,ST,ADI,NXP,LATTICE,CYPRESS,INFINEON,XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.
A: You can inquire through the website, or by phone and email.
A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.
A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
