AD5243BRMZ50 is a dual-channel, 256-bit digital potentiometer housed in a compact 10-pin MSOP package. It supports an I²C-compatible interface and is suitable for applications requiring precise resistance adjustment.

AD5243BRMZ50 Specifications

Dual-channel, 256-step potentiometer

End-to-end resistance: 2.5 kΩ, 10 kΩ, 50 kΩ, and 100 kΩ

Compact 10-pin MSOP (3 mm × 4.9 mm) package

Fast settling time: tS = 5 µs (typical at power-up)

Full read/write cursor register

Power-up preset to mid-range value

Computer software replaces microcontroller in factory programming applications

Single supply: 2.7 V to 5.5 V

Low temperature coefficient: 35 ppm/°C

Low power consumption: IDD = 6 µA (maximum)

Wide operating temperature range: −40°C to +125°C

AD5243BRMZ50 Applications

System calibration

Electronic equipment level setting

Replacement for mechanical adjusters in new designs

Permanent factory printed circuit board (PCB) setting

Pressure, temperature, position, chemical and optical sensor adjustment

RF amplifier bias

Gain control and offset voltage adjustment
