The MIC2026-1YM-TR is a high-side MOSFET switch optimised for general-purpose power distribution requiring circuit protection. This device incorporates internal current limiting and thermal shutdown protection mechanisms to safeguard both the device itself and the load. Upon thermal shutdown fault occurrence, the output remains locked in the off state until the faulty load is removed. The device output resets by removing the load or switching the enable input. Both devices incorporate a soft-start circuit to minimise inrush current in high-capacitance load applications. A fault status output flag is triggered during overcurrent and thermal shutdown conditions. Transient faults are filtered internally.

MIC2026-1YM-TR Product Attributes

Manufacturer:    Microchip

Product Type:    Power Switch IC - Distribution

Type:    High Side

Number of Outputs:    2 Output

Output Current:    500 mA

Current Limit:    900 mA

On-Resistance—Maximum:    140 mOhms

Turn-On Time—Maximum:    5 ms

Turn-Off Time—Maximum:    100 us

Operating Supply Voltage:    2.7 V to 5.5 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

Mounting Style:    SMD/SMT

Package / Case:    SOIC-8

Humidity Sensitivity:    Yes

Supply Voltage - Maximum:    5.5 V

Supply Voltage - Minimum:    2.7 V

MIC2026-1YM-TR Product Features

Maximum on-resistance per channel: 140mΩ

Operating voltage range: 2.7V to 5.5V

Minimum continuous current per channel: 500mA

Short-circuit protection with thermal shutdown

Thermally isolated channels

Fault status flag with 3ms filter to eliminate false triggering

Undervoltage lockout

Reverse current blocking (no ‘body diode’)

Circuit breaker mode (MIC2076)

Logic-compatible inputs

Soft-start circuitry

Low quiescent current
