ADRF5474BCZ - 10MHz to 60GHz, 2dB LSB, 4-Bit, Die on Carrier, Silicon Digital Attenuator

Product Overviews

ADRF5474BCZ is a 4-bit digital attenuator with 22 dB attenuation control range in 2 dB steps manufactured in a silicon process attached on a gallium arsenide (GaAs) carrier substrate. The substrate incorporates the bond pads for chip and wire assembly, and the bottom of the device is metalized and connected to ground. This device operates from 10 MHz to 60 GHz with better than 2.7 dB of insertion loss and excellent attenuation accuracy at 55 GHz. The ADRF5474 has a RF input power handling capability of 23 dBm average and 24 dBm peak for all states.

Key Features

Ultrawideband frequency range: 10 MHz to 60 GHz

Attenuation range: 22 dB with 2 dB steps

Bond pads for wire bond and ribbon bond

Low insertion loss

- 1.3 dB typical up to 20 GHz

- 2.0 dB typical up to 44 GHz

- 2.7 dB typical up to 55 GHz

High input linearity

- P0.1dB: 25.5 dBm typical

- IP3: 45 dBm typical

Tight distribution in relative phase

No low frequency spurious signals

Parallel mode control, CMOS/LVTTL compatible

RF amplitude settling time (0.1 dB of final RF output): 175 ns

16-pad, 2.770 mm × 1.620 mm, die on carrier [CHIP]

Applications

Industrial scanners

Test and instrumentation

Cellular infrastructure: 5G millimeterwave

Military radios, radars, electronic counter measures (ECMs)

Microwave radios and very small aperture terminals (VSATs)
