The OPA2171AQDGKRQ1 is a series of 36V, single-supply, low-noise operational amplifiers that can operate within a power supply voltage range of 2.7V (±1.35V) to 36V (±18V). These devices feature a miniature package and offer low offset voltage, low drift, low bandwidth, and low quiescent current. Single-channel, dual-channel, and quad-channel versions share the same technical specifications, providing greater design flexibility.

OPA2171AQDGKRQ1 Features

• Power supply voltage range: 2.7V to 36V, ±1.35V to ±18V

• Low noise: 14nV/√Hz

• Low temperature drift: ±0.3µV/°C (typical)

• RFI-filtered input

• Input range includes negative supply voltage

• Input range includes positive supply voltage

• Rail-to-rail output

• Gain bandwidth: 3MHz

• Low quiescent current: 475µA per amplifier

• High common-mode rejection: 120dB (typical)

• Low input bias current: 8pA

• Miniature package: Dual-channel version in VSSOP-8 package

OPA2171AQDGKRQ1 2 Applications

• Tracking amplifiers in power modules

• Commercial power supplies

• Sensor amplifiers

• Bridge amplifiers

• Temperature measurement

• Strain gauge amplifiers

• Precision integrators

• Battery-powered instruments

• Test equipment
