TLV4316IPWR is a four-channel, low-power, rail-to-rail input/output (RRIO) operational amplifier. This product is packaged in a TSSOP-14 package and is suitable for a variety of low-voltage applications.

TLV4316IPWR Features

Unit gain bandwidth: 10MHz

Low IQ: 400µA per channel

Excellent power-to-bandwidth ratio

Stable IQ across temperature and supply voltage ranges

Wide supply voltage range: 1.8V to 5.5V

Low noise: 12nV/√Hz at 1kHz

Low input bias current: ±10pA

Offset voltage: ±0.75mV

Unit gain stability

Internal RF interference (RFI)/electromagnetic interference (EMI) filter

Extended temperature range: -40°C to +125°C

TLV4316IPWR Specifications

Gain-bandwidth product: 10MHz

Input bias current: 10pA

Input offset voltage: 750 μV

Output current: 50 mA

Operating voltage range: 1.8 V to 5.5 V

Operating temperature range: -40°C to +125°C

Slew rate: 6 V/μs

TLV4316IPWR Application Areas

Battery-powered instruments:

Consumer applications, industrial applications, medical applications

Laptops, portable media players

Sensor signal conditioning

Barcode scanners

Active filters

Audio
