The TLV9104IDR is a 16V general-purpose operational amplifier. This device offers excellent DC accuracy and AC performance, including rail-to-rail input/output, low offset voltage (±300µV, typical), low temperature drift (±0.6µV/°C, typical), and a 1.1MHz bandwidth.

The TLV9104IDR offers a wide differential and common-mode input voltage range, high output current (±80mA, typical), high slew rate (4.5V/µs, typical), low power consumption (115µA, typical), and shutdown functionality, making it a stable, low-power, high-performance operational amplifier suitable for a wide range of industrial applications.

The TLV9104IDR operational amplifier is available in miniature and standard packages, with an operating temperature range of -40°C to 125°C.

TLV9104IDR Features

Rail-to-rail input and output

High bandwidth: 1.1MHz GBW

Low quiescent current: 120µA per amplifier

Low offset voltage: ±300µV

Low offset voltage drift: ±0.6 µV/°C

Low noise: 28 nV/√Hz at 10 kHz

High common-mode rejection: 110 dB

Low bias current: ±10 pA

High slew rate: 4.5 V/µs

Wide supply voltage range: ±1.35 V to ±8 V, 2.7 V to 16 V

Robust EMIRR performance: 77 dB at 1.8 GHz

TLV9104IDR Applications

• Optical modules

• Portable test and measurement

• Macro remote radio units (RRU)

• Baseband units (BBU)

• Appliances
