The TLV9101SIDBVR is a single-channel, low-power operational amplifier designed specifically for low-voltage applications. It features rail-to-rail input and output capability and operates over a wide supply voltage range (2.7V to 16V), making it ideal for a variety of industrial and consumer applications.

TLV9101SIDBVR Product Features

Rail-to-rail input and output: Ensures accurate amplification and transmission of signals across the entire power supply range.

High bandwidth: Gain-bandwidth product (GBP) of 1.1MHz, capable of handling high-frequency signals.

Low quiescent current: Each amplifier has a quiescent current of only 120µA, helping to reduce power consumption and making it suitable for battery-powered devices.

Low offset voltage: ±300 µV (typical), ensuring high-precision signal processing.

Low offset voltage drift: ±0.6 µV/°C (typical), improving temperature stability.

Low noise: 28 nV/√Hz at 10 kHz, reducing noise interference during signal processing.

High slew rate: 4.5 V/µs (typical), ensuring fast signal response.

Wide power supply voltage range: Supports ±1.35 V to ±8 V (dual power supply) or 2.7 V to 16 V (single power supply), accommodating various power supply environments.

Strong electromagnetic interference (EMI) suppression capability: Reaches 77 dB at 1.8 GHz, enhancing interference resistance.

TLV9101SIDBVR Product Specifications

Package type: SOT-23-6

Gain-bandwidth product (GBP): 1.1MHz

Quiescent current: 120µA

Offset voltage: ±300µV (typical)

Offset voltage drift: ±0.6µV/°C (typical)

Input Noise Current Density: 2fA/√Hz

Supply Voltage Range: 2.7V to 16V (single supply), ±1.35V to ±8V (dual supply)

Operating Temperature: -40°C to 125°C

Slew Rate: 4.5V/µs (typical)

Common-Mode Rejection Ratio (CMRR): 110dB (typical)

TLV9101SIDBVR Applications

Optical modules

Portable test and measurement

Macro remote radio units (RRU)

Baseband units (BBU)

Electrical appliances
