Service Telephone:86-755-83294757
Trade Name:RS-232 Interface Integrated Circuit
Brand:Maxim
Particular Year:21+
Package:SSOP-16
Delivery Date:New and Original
Stock: 6000pcs
The MAX3221CAE is a single-channel, true RS-232 transceiver with an integrated charge pump that requires only a single +3 V to +5.5 V power supply to generate standard ±5 V RS-232 levels. Features AutoShutdown™ intelligent power-saving functionality, which automatically shuts down the charge pump and driver after 30 µs of no valid signal detection, with a shutdown current of only 1 µA, making it ideal for battery-powered or power-sensitive applications.
MAX3221CAE Key Features
• Fully compliant with the TIA/EIA-232-F standard
• Single power supply: +3.0 V to +5.5 V
• AutoShutdown™: automatically enters 1 µA ultra-low power standby mode
• Data rate: up to 235 kbps
• 1 driver + 1 receiver (1T/1R)
• ±15 kV ESD (HBM) protection (RS-232 bus side)
• Receiver hysteresis: typical 300 mV, enhanced noise suppression
• Shutdown control pin (FORCEOFF) and wake-up pin (FORCEON)
• Operating temperature: 0 °C to +70 °C (commercial grade)
• Package: 16-SSOP (5.30 mm wide) surface mount
MAX3221CAE Specifications
Supply voltage: 3.0 V to 5.5 V
Shutdown current: 1 µA (typical)
Data rate: 235 kbps
Driver output swing: ±5 V @ 3 kΩ load
Receiver input range: ±25 V fault-tolerant
ESD rating: ±15 kV HBM
Operating temperature: 0 °C to +70 °C
Package: 16-SSOP
MAX3221CAE Applications
Battery-powered devices
Handheld devices
Peripherals
Portable diagnostic devices
Model
Brand
Package
Quantity
Describe
TI
TSSOP-28
4000
RS-232 Interface Integrated Circuit 3-5.5V MultiCh Line Driver/Receiver
Maxim
TSSOP-20
5000
RS-232 interface integrated circuit 1 A supply current, true +3V to +5.5V RS
