The MAX3243ECPWR is a high-performance, low-power RS-232 transceiver chip. The device comprises three line drivers, five line receivers, and a dual charge pump circuit, offering ±15kV ESD protection (HBM and IEC61000-4-2, air gap discharge) and ±8kV ESD protection (IEC61000-4-2, contact discharge) on the serial port connection pins. The device complies with TIA/EIA-232-F requirements and provides an electrical interface between asynchronous communication controllers and serial port connectors. This combination of drivers and receivers meets or is compatible with the requirements for typical serial ports used in IBM PC/AT systems. The charge pump and four small external capacitors support operation from a single 3V to 5.5V supply. Additionally, the device incorporates a permanently active common-mode output (ROUT2B), enabling applications utilising ring indication to transmit data even when the device is powered down.

Features of the MAX3243ECPWR

Single-chip, single-supply interface for IBM™ PC/AT™ serial ports

ESD protection for RS-232 bus pins

±15kV Human Body Model (HBM)

±8kV IEC61000-4-2, contact discharge

±15kV IEC61000-4-2 air gap discharge

Meets or exceeds TIA/EIA-232-F and ITU V.28 standards

Operates from 3V to 5.5V VCC supply

Always-active common-mode receiver output (ROUT2B)

Designed for data transmission at rates up to 500kbit/s

Low standby current: 1µA (typical)

External capacitors: 4 × 0.1µF

Accepts 5V logic inputs and 3.3V supply

Designed for interchangeability with Maxim MAX3243E

Serial mouse driver capability

Auto-power-down function disables driver outputs when no valid RS-232 signal is detected

MAX3243ECPWR Specifications

Manufacturer: Texas Instruments

Product Type: RS-232 Interface Integrated Circuit

Package/Case: TSSOP-28

Series: MAX3243E

Function:    Transceiver

Data Rate:    500 kb/s

Number of Drivers:    3 Driver

Number of Receivers:    5 Receiver

Duplex:    Full Duplex

Supply Voltage - Maximum:    5.5 V

Supply Voltage - Minimum:    3 V

Mounting Style:    SMD/SMT

Operating Supply Current:    1 mA

Minimum Operating Temperature:    0 °C

Maximum Operating Temperature:    +70°C

ESD Protection:    15 kV

Applications for MAX3243ECPWR

• Battery-powered systems

• Wired networks

• Data centres and enterprise computing

• Battery-powered systems

• Laptops

• Portable computers

• Handheld computers

• Handheld devices
