IPLU300N04S4-R8 is based on Infineon's OptiMOS™ 5 technology and is specifically designed for high-current, high-density automotive applications. It adopts the next-generation TOLL (TOLL-8 / HSOF-8) packaging, reducing the area by 23% and height by 47% compared to traditional D²Pack, while supporting a continuous drain current of 300 A, addressing the dual challenges of efficiency and size in 12 V / 48 V automotive power systems.

IPLU300N04S4-R8 Features

N-channel - Enhancement mode

Compliant with automotive electronics grade AEC Q101 standard

MSL1 grade, peak reflow temperature up to 260°C

Operating temperature up to 175°C

Environmentally friendly product (compliant with RoHS standard)

100% avalanche tested

Ultra-low RDS (on-state)

Device supporting PPAP certification

IPLU300N04S4-R8 Product Attributes

Product Type: MOSFET

Technology: Si

Mounting Style: SMD/SMT

Package/Case: H-PSOF-8

Transistor Polarity: N-Channel

Number of Channels: 1 Channel

Vds - Drain-Source Breakdown Voltage: 40 V

Id - Continuous Drain Current:    300 A

Rds On - Drain-Source On-Resistance:    770 uOhms

Vgs - Gate-Source Voltage: - 20 V, + 20 V

Vgs th-Gate-Source Threshold Voltage:    2 V

Qg-Gate Charge:    221 nC

Minimum Operating Temperature:    - 55 °C

Maximum Operating Temperature:    + 175 °C

Power Dissipation (Pd):    429 W

Channel Mode:    Enhancement

Qualification:    AEC-Q101

IPLU300N04S4-R8 Applications

Automotive Secondary Power Distribution Unit

Chassis Control and Safety Systems

Electronic Stability Control Systems

On-Board Charging Systems (OBC)
