The IPD90P03P4L-04 is an automotive MOSFET offering 30V, P-channel, 4.5 mΩ max, DPAK, OptiMOS™-P2, ideal for battery reverse protection.

Functional Overview (IPD90P03P4L-04)

P-Channel - Logic Level - Enhanced Mode

AEC Approved

MSL1 Peak Reflow Temperature up to 260°C

175°C operating temperature

Green package (RoHS compliant)

100% avalanche tested

For battery reverse protection

Product Attributes (IPD90P03P4L-04)

Product Category: MOSFETs

Technology: Si

Mounting Style: SMD/SMT

Package / Case: DPAK-3 (TO-252-3)

Transistor Polarity: P-Channel

Number of Channels: 1 Channel

Vds-Drain-source breakdown voltage: 30 V

Id-Continuous drain current: 90 A

Rds On-drain on-resistance: 4.1 mOhms

Vgs - gate-source voltage: - 16 V, + 5 V

Vgs th - gate-source threshold voltage: 1.5 V

Qg - gate charge: 125 nC

Minimum operating temperature: - 55 C

Maximum operating temperature: + 175 C

Pd-power dissipation: 137 W

Channel mode: Enhancement

Applications (IPD90P03P4L-04)

Automotive Gateway

Automotive USB Power Delivery

Home Robotics

Electric Vehicle (EV) Drivetrain

Electric Vehicle Traction Inverter
