Service Telephone:86-755-83294757
Trade Name:Automotive MOSFET
Brand:INFINEON
Particular Year:25+
Package:PG-TDSON-8
Delivery Date:New and Original
Stock: 25000pcs
The IPC100N04S5L-1R5 is an OptiMOS™ family of automotive-grade power MOSFETs, which are N-channel enhancement devices designed for high-reliability, high-efficiency automotive electronics applications. Its core strengths include extremely low on-resistance (RDS(on)), high current carrying capability (100A), and AEC-Q101 certification for harsh automotive environments.
Features - IPC100N04S5L-1R5
OptiMOS™ - Power MOSFETs for automotive applications
N-Channel - Enhanced Mode - Logic Levels
AEC Q101 certified
MSL1 Peak Reflow Temperature up to 260°C
175°C operating temperature
Green product (RoHS compliant)
100% avalanche tested
Product Attributes - IPC100N04S5L-1R5
Series: OptiMOS™
FET Type: N-Channel
Technology: MOSFET (Metal Oxide)
Drain-Source Voltage (Vdss): 40 V
Current at 25°C - Continuous Drain (Id): 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
On Resistance (Max) at Different Id, Vgs: 1.5 mOhm @ 50A, 10V
Vgs(th) at different Id (max): 2V @ 60µA
Gate Charge (Qg) (Max) at Vgs: 95 nC @ 10 V
Vgs (max): ±16V
Input capacitance (Ciss) at varying Vds (max): 5340 pF @ 25 V
Power Dissipation (Max): 115W (Tc)
Operating Temperature: -55°C ~ 175°C (TJ)
Grade: Automotive Grade
Qualification: AEC-Q101
Mounting Type: Surface Mount
Supplier Device Package: PG-TDSON-8-34
Package/Housing: 8-PowerTDFN
