Commodity Model:LTC3704EMS

Trade Name:Switch Controller

Brand:ADI

Particular Year:18+

Package:MSOP-10

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
LTC3704EMS
Package
MSOP-10
Describe
Wide input range, No RSENSE™ Wide input range, positive to negative DC/DC controller

Product Description

The LTC3704EMS is a wide input range, current mode, positive-to-negative DC/DC controller designed to drive an N-channel power MOSFET with minimal external components. The LTC3704EMS is suitable for low to high power applications and eliminates the need for an additional current sense resistor by utilising the on-resistance of the power MOSFET, thereby maximising efficiency.


The operating frequency of this IC can be set within the range of 50kHz to 1MHz using an external resistor, or synchronised to an external clock via the MODE/SYNC pin. Due to its burst mode operation under light load conditions, the LTC3704 features a low minimum operating supply voltage of 2.5V and a low shutdown quiescent current of 10μA, making it an ideal choice for battery-powered systems.


For applications requiring constant frequency operation, the MODE/SYNC pin can be used to disable burst mode operation. By connecting the SENSE pin to a resistor located at the source of the power MOSFET, the LTC3704EMS can be used in applications where the switching voltage exceeds 36V.


The LTC3704EMS is available in a 10-pin MSOP package.


LTC3704EMS Features

High-efficiency operation (no detection resistor required)

Wide input voltage range: 2.5V to 36V

Current-mode operation provides excellent transient response

High maximum duty cycle (typical value of 92%)

±1% internal voltage reference

±2% RUN pin threshold (with 100mV hysteresis)

Micro-power shutdown mode: IQ = 10μA

Operating frequency can be set using an external resistor (50kHz to 1MHz)

Can be synchronised to an external clock with a frequency up to 1.3 x fOSC

User-controlled pulse skipping or Burst Mode® operation

Internal 5.2V low dropout voltage regulator

Can operate with a sense resistor to suit high output voltage applications (VDS > 36V)

Small 10-pin MSOP package


LTC3704EMS Applications

Subscriber Line Interface Circuit (SLIC) power supply

Telecom power supply

Portable electronic devices

Cable and DSL modems

Router power supply
