The LTC3805IDD is a current mode controller for flyback DC/DC converters designed to drive an N-channel MOSFET in high input and output voltage converter applications. The operating frequency and slope compensation can be set using external resistors. A programmable overcurrent detection circuit protects the converter from short-circuit damage. The soft-start function can be set with an external capacitor, and the soft-start capacitor is also used to set an automatic restart function.

The LTC3805IDD provides ±1.5% output voltage accuracy and has a quiescent current consumption of only 360μA during normal operation and 40μA during micropower startup. Using a 9.5V internal shunt regulator, the LTC3805IDD can be powered from the high VIN through a resistor or directly from a low impedance DC voltage of 9V or less. The LTC3805IDD can be powered from a high VIN through a resistor or directly from a low impedance DC voltage of 9V or less using a 9.5V internal shunt regulator.

LTC3805IDD Product Attributes

Output Type: Transistor Driver

Function: Boost/Buck

Output Configuration: Positive, Isolation Available

Topology: Flyback

Number of Outputs: 1

Output Stage: 1

Voltage - Supply (Vcc/Vdd): 3.95V ~ 9.5V

Frequency - Switching: 70kHz ~ 700kHz

Duty Cycle (Maximum): 80%

Synchronous Rectifier: No

Clock Synchronisation: Yes

Control Characteristics: Enable, Soft Start

Operating Temperature: -40°C ~ 125°C (TJ)

Mounting Type: Surface Mount

Package/Housing: 10-WFDFN Undeposited Pad

Supplier Device Package: 10-DFN (3x3)

LTC3805IDD Applications

Telecom power supplies

42V and 12V automotive power supplies

Isolated electronic devices
