Commodity Model:AD9250BCPZ-250

Trade Name:Analogue To Digital Converters - ADC

Brand:ADI

Particular Year:25+

Package:LFCSP-48

Delivery Date:New and original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
AD9250BCPZ-250
Package
LFCSP-48
Describe
14-bit, 250 MSPS, JESD204B, dual-channel analog-to-digital converter

Product Description

The AD9250BCPZ-250 device is a dual-channel 14-bit ADC launched by Analog Devices (ADI), with a maximum sampling rate of 250 MSPS. It is designed to provide solutions for low-cost, small-sized, wide-bandwidth, and multi-functional communication applications. The following are its technical parameters:

Number of digits: 14

Sampling rate (per second) : 250M

Input number: 2

Input type: Difference

Data interface: JESD204B

Configuration: S/H-ADC

Ratio - S/H:ADC: 1:1

A/D converter number: 2

Architecture: Pipeline

Reference type: Internal

Voltage - Power supply, analog: 1.7V to 1.9V

Voltage - power supply, number: 1.7V to 1.9V

Feature: Synchronous sampling

Operating temperature: -40°C to 85°C

Packaging/Housing: 48-LFCSP


The AD9250BCPZ-250 core adopts a multi-level, differential pipeline architecture and integrates output error correction logic. The ADC core features a wide bandwidth input and supports various input ranges selectable by users. Integrated reference voltage sources can simplify the design. Duty cycle stabilizers can be used to compensate for the fluctuations in the duty cycle of the ADC clock, enabling the converter to maintain excellent performance. The JESD204B high-speed serial interface can reduce the wiring requirements of circuit boards and decrease the number of pins needed for receiving devices.


Product Features

Integrated dual-channel, 14-bit, 170 MSPS/250 MSPS ADC.

The configurable JESD204B output module supports a maximum sampling rate of 5 Gbps per channel.

The on-chip phase-locked loop (PLL) enables users to provide a single ADC sampling clock, and the corresponding JESD204B data rate clock is generated by multiplying the PLL by this ADC sampling clock.

Support optional RF clock input to simplify the system board design.

The patented differential input maintains excellent signal-to-noise ratio (SNR) performance even at input frequencies up to 400 MHz.

It is powered by a single 1.8V power supply.

The Standard Serial Port Interface (SPI) supports various product features and functions, such as: control clock DCS, power-saving mode, test mode, reference voltage mode, rapid out-of-range detection, and serial output configuration, etc.
