Commodity Model:ADP7157ACPZ-04

Trade Name:LDO Linear Voltage Regulators

Brand:ADI

Particular Year:25+

Package:LFCSP-10

Delivery Date:New and original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
ADP7157ACPZ-04
Package
LFCSP-10
Describe
1.2A, ultra-low noise, high PSRR, adjustable output, RF linear regulator

Product Description

The ADP7157ACPZ-04 is an adjustable linear voltage regulator, powered by a 2.3V to 5.5V supply, with a maximum output current of 1.2A. This device adopts an advanced proprietary architecture, offering high power supply suppression and ultra-low noise characteristics. It only requires a 10 μF ceramic output capacitor to achieve outstanding line and load transient response performance.


Core features

Input voltage range: 2.3V to 5.5V

Adjustable output voltage range (VOUT) : 1.2V to 3.3V

Maximum load current: 1.2A

Low noise

Output noise from 100 Hz to 100 kHz: 0.9 µV rms (typical value)

Output noise from 10 Hz to 100 kHz: 1.6 µV rms (typical value)

Noise spectral density: 1.7 nV/√Hz (10 kHz to 1 MHz)

Power Supply Rejection Ratio (PSRR

82 dB (1 kHz to 100 kHz)

55 dB (1 MHz)

Voltage difference: 120 mV (typical value, IOUT = 1.2A, VOUT = 3.3V)

Initial accuracy: ±0.6% (when ILOAD = 10 mA)

Accuracy across the entire line, load and temperature range: ±1.5%

Working power supply current (IGND

4.0 mA (typical value, 0 µA)

7.0 mA (typical value, 1.2 A)

Low turn-off current: 0.2 μA (typical value

Maintain stability using a 10 µF ceramic output capacitor

10-pin 3mm x 3mm LFCSP package

Precision enabling

ADIsimPower tool support


Typical applications

The ADP7157ACPZ-04 is suitable for noise-sensitive applications: phase-locked loop (PLL), voltage-controlled oscillator (VCO), and PLL with integrated VCO

Communication and infrastructure

Return route and microwave link
