The TMS320F28235ZJZQR is a 32-bit automotive-grade microcontroller (MCU) from Texas Instruments, part of the C2000™ C28x Delfino™ series, specifically designed for real-time control applications such as industrial motor drives, photovoltaic inverters, digital power supplies, and electric vehicle control systems. The chip is based on a high-performance C28x core, supports a 150MHz clock speed, and integrates 512KB of flash memory and 34KB of RAM, featuring a rich set of peripheral interfaces, making it suitable for high-precision closed-loop control scenarios.

Core Parameters (TMS320F28235ZJZQR)

CPU: C28x, 32-bit, maximum operating frequency 150MHz

Storage: 512KB Flash, 68KB RAM

Operating Temperature: -40°C to +125°C (TA), compliant with AEC-Q100 standards

Package: 176-pin PBGA (ZJZ)

I/O Count: Up to 88 programmable GPIO pins

Core Features (TMS320F28235ZJZQR)

High-Performance Processing Capability: With a CPU clock speed of up to 150MHz, it achieves a processing capability of 150MIPS per second, suitable for complex control algorithms and high-speed data processing.

Rich Peripheral Interfaces: Integrated with multiple communication interfaces, including 2 CAN modules, 3 SCI (UART) modules, 2 McBSP modules (configurable as SPI), 1 SPI module, and 1 I2C bus, to meet communication requirements across various application scenarios.

High-precision ADC: Features a built-in 12-bit ADC with 16 channels, a conversion rate of 80ns, and support for internal or external reference, enabling high-precision analogue signal acquisition.

Powerful Timer Functions: Equipped with 3 32-bit CPU timers, up to 8 32-bit timers, and 9 16-bit timers, supporting various timing and counting functions.

Enhanced PWM: Supports up to 18 PWM outputs, including up to 6 HRPWM outputs, with a MEP resolution of 150ps, suitable for high-precision motor control and power management.

Flexible memory configuration: Features a 16-bit or 32-bit external interface (XINTF), supporting an address range exceeding 2Mx16, enabling expansion of external memory to meet larger storage requirements.

Low-power modes: Supports multiple low-power modes such as IDLE, STANDBY, and HALT, effectively reducing system power consumption, suitable for power-sensitive applications.

Applications (TMS320F28235ZJZQR)

• Advanced Driver Assistance Systems (ADAS)

– Mid/short-range radar

• Building automation

– HVAC motor control

– Traction inverter motor control

• Factory automation and control

– Automatic sorting equipment

– CNC control

• Grid infrastructure

– Central inverter

– String inverters

• Hybrid, electric, and powertrain systems

– Inverter and motor control

– On-board chargers (OBC) and wireless chargers

• Motor drives

– AC input BLDC motor drivers

– Servo drive control modules

• Power distribution

– Industrial AC/DC power supplies
