The UCC5390ECDWVR is a single-channel isolated gate driver from Texas Instruments, packaged in an 8-SOIC package, specifically designed for driving power switching devices (such as IGBTs, SiC MOSFETs, and GaN FETs) in high-voltage, high-noise environments. Its key features include a 3kVrms isolation voltage, 10A peak output current, and 100kV/µs common-mode transient immunity (CMTI), making it suitable for applications such as industrial power supplies, motor drives, photovoltaic inverters, and electric vehicle charging systems.

UCC5390ECDWVR Core Features

High isolation voltage: 3000Vrms (1 minute), compliant with UL 1577 and VDE V 0884-11 safety certifications.

Capacitive coupling isolation technology, with an isolation layer lifespan exceeding 40 years.

High-speed drive capability: 10A peak output current, enabling rapid switching of SiC/GaN power devices.

Propagation delay ≤100ns, rise/fall time 10ns, optimising high-frequency switching efficiency.

Strong anti-interference performance: CMTI ≥100kV/µs, preventing noise-induced false triggering.

Input side supports -5V negative voltage, enhancing system robustness.

Wide power supply range: input voltage 3V to 15V, drive-side voltage 13.2V to 33V, compatible with various power architectures.

Industrial-grade reliability: operating temperature -40°C to +125°C, suitable for harsh environments.

Compliant with CQC, CSA, VDE, and other certifications.

UCC5390ECDWVR Product Attributes

Product Type: Current-isolated gate driver

Series: UCC5390

Mounting Style:    SMD/SMT

Package/Case:    SOIC-8

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Pd - Power Dissipation:    1.04 W

Propagation Delay - Maximum:    100 ns

Rise Time:    10 ns

Fall Time:    10 ns

Logic Type:    CMOS

Humidity Sensitivity:    Yes

Driver Count:    1 Driver

Output Count:    1 Output

Operating Supply Current:    1.67 mA

Output current:    10 A

Output voltage:    13.2 V to 33 V

Supply voltage—maximum:    15 V

Supply voltage—minimum:    3 V

UCC5390ECDWVR Typical Applications

Motor drivers (industrial servo, electric vehicle drive)

Photovoltaic/energy storage inverters

High-voltage DC-DC converters

UPS uninterruptible power supplies

Electric vehicle charging stations (OBC, DC-DC)
