The TPSM84624MOLR power module is an easy-to-use integrated power supply that combines a 6A DC/DC converter with a power MOSFET, a shielded inductor, and multiple passive components within a compact QFM package. This power solution requires only six external components while still allowing for adjustment of key parameters to meet specific design requirements. The TurboTrans™ feature enables ultra-fast transient response. TurboTrans enables optimisation of transient response to reduce output voltage deviation and lower the required output capacitance.

The TPSM84624MOLR features a 7.5mm × 7.5mm × 5.3mm, 24-pin QFM package that is easy to solder onto a printed circuit board and offers excellent power dissipation capability. The TPSM84624 is highly flexible and offers numerous features, including normal power supply, programmable UVLO, tracking, pre-bias start-up, and overcurrent and over-temperature protection, making it an excellent choice for powering a wide range of devices and systems.

Features Of the TPSM84624MOLR

• Integrated inductor power supply solution

• 7.5mm × 7.5mm × 5.3mm QFM package

– All pins are distributed around the package perimeter

• Input voltage range: 4.5V to 17V

• Wide output voltage range: 0.6V to 10V

• Efficiency up to 96%

• Adjustable fixed switching frequency (200kHz to 1.6MHz)

• Supports synchronization with an external clock

• Ultra-fast load step response (TurboTrans™)

• Normal power output

• Complies with EN55011 Class B radiation emission limits

• Operating temperature range: -40°C to +105°C

• Operating IC junction temperature range: -40°C to +150°C

• Use the TPSM84624 and leverage WEBENCH® Power Designer to create custom design solutions

Applications Of the TPSM84624MOLR

• Telecommunications and wireless infrastructure

• Industrial automation test equipment

• Enterprise switching and storage applications

• High-density distributed power systems
