The NCV7754DPR2G is an automotive-grade 8-channel low-side drive that offers up to 500 mA of drive capability per channel. Output control is carried out through the SPI port, which can conveniently report faults in open-circuit loads (or short circuits to ground), overloads and over-temperature conditions. In addition, the parallel control of the output of NCV7754DPR2G can be addressed through the INx pins (in pairs). The dedicated limp-origin mode pins (LHI) enable OUT1-OUT4 while disabling OUT5-OUT8. Each output driver is equipped with overload current protection and includes an output clamp for inductive loads.

Target application

• Automobile body control unit

• Automobile engine control unit

• Relay drivers

• LED Driver

• Stepper motor driver

In addition, NCV7754DPR2G also has the following technical parameters:

Switch type: Relay, solenoid driver

Output number: 8

Ratio - Input: Output: 1:8

Output configuration: Low-end

Output type: N channel

Interface: SPI

Voltage - Load: 36V (Maximum)

Voltage - Power Supply (Vcc/Vdd) : 3V to 5.5V

Current - Output (maximum value) : 500mA

On-resistance (typical value) : 800 milliohms

Input type: -

Feature: -

Fault protection: Open-circuit load detection, over-temperature

Operating temperature: -40°C to 150°C (TJ)

Grade: Automotive grade

Qualification: AEC-Q100

Installation type: Surface mount type

Device packaging: 24-SSOP
