The NCV7750DPR2G is an automotive eight-channel low-voltage side drive that offers a driving capacity of up to 600 mA per channel. Output control is carried out through the SPI port, providing convenient fault reports for open-circuit loads (or ground short circuits), overloads and high-temperature conditions. In addition, the parallel control of the output of NCV7750DPR2G can be addressed through the INx pin. The dedicated backline return mode pins (LHI) enable OUT1 to OUT4. Each output driver is equipped with overload current protection and includes an output clamp for inductive loads. The NCV7750DPR2G adopts an SSOP24 package with a fuse lead.

Technical Specification

Switch type: Relay, solenoid driver

Output number: 4

Ratio - Input: Output: 1:4

Output configuration: Low-end

Output type: N channel

Interface: SPI

Voltage - Load: 36V (Maximum)

Voltage - Power Supply (Vcc/Vdd) : 3V to 5.5V

Current - Output (maximum value) : 600mA

On-resistance (typical value) : 1.1 ohms

Input type: -

Feature: -

Fault protection: Open-circuit load detection, over-temperature

Operating temperature: -40°C to 150°C (TJ)

Grade: Automotive grade

Qualification: AEC-Q100

Installation type: Surface mount type

Device packaging: 24-SSOP

Typical applications of NCV7750DPR2G

Automobile body control unit

Automobile engine control unit

Relay drive

LED driver

Stepper motor driver
