Trade Name:High Side Driver
Brand:ST
Particular Year:25+
Package:SO-8
Delivery Date:New and Original
Stock: 18000pcs
The VN7140ASTR are single-channel high voltage side drivers, manufactured using ST's proprietary VIPower M0-7 technology in an SO-8 package. The devices are designed to drive 12 V automotive grounded loads over 3 V and 5 V CMOS compatible interfaces and provide protection and diagnostic functions.
The devices incorporate advanced protection features such as load current limiting, active management of overloads through power limiting, and overtemperature shutdown (configurable latching).
The FaultRST pin unlocks the output or disables the latch function in the event of a fault.
Dedicated multi-function multiplexed analogue output pins provide sophisticated diagnostics, including high-precision proportional load current sensing, supply voltage feedback and chip temperature sensing, as well as overload and short-to-ground, short-to-VCC and off-state open load detection.
The sense enable pin allows shutdown diagnostics to be disabled in the module's low-power mode and external sense resistors to be shared between similar devices.
VN7140ASTR Device Attributes
Switch Type: General Purpose
Number of Outputs: 1
Ratio - Input:Output: 1:1
Output Configuration: High Side
Output Type: N-Channel
Interface: On/Off
Voltage - Load: 4V ~ 28V
Voltage - Supply (Vcc/Vdd): Not Required
Current - Output (Max): 8A
On Resistance (Typ): 140 mOhm
Input Type: Non-Inverting
Features: Auto Restart, Status Flags
Fault Protection: Current Limit (Fixed), Open Load Detection, Over Temperature, Over Voltage, UVLO
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Applications
All types of automotive resistive, inductive and capacitive loads
Particularly suitable for automotive signalling (up to R10W or LED rear combination lights)
Protective power supplies for ADAS systems: radar and sensors
Model
Brand
Package
Quantity
Describe
ON
SOIC-8
3000
Self Protected High Side Driver with Temperature Shutdown and Current Limit
