THVD1451DR is a high-performance RS-485/RS-422 transceiver in an SOIC-8 package, designed for industrial automation, process control, instrumentation, and other applications. The chip supports data transfer rates of up to 50 Mbps and features ±18 kV IEC ESD protection, making it suitable for long-distance communication in harsh electromagnetic environments.

THVD1451DR Key Features

Communication Protocol Support

RS-485 (multi-point communication) & RS-422 (point-to-point communication).

1/8 unit load, supporting up to 256 bus nodes.

Signal Integrity Optimisation

Differential signal transmission to suppress common-mode noise.

30mV receiver hysteresis to enhance interference resistance.

Protection Mechanisms

Short-circuit protection to prevent output damage.

Overvoltage protection (-18V to 18V) to enhance system safety.

Flexible Power Supply

Wide voltage input range of 3V to 5.5V, compatible with 3.3V/5V systems.

THVD1451DR Key Parameters

Data rate: Up to 50Mbps

Supply voltage: 3V to 5.5V

ESD protection: ±18kV (IEC 61000-4-2 contact discharge)

Common-mode voltage range: ±15V

Package: SOIC-8

Operating temperature: -40°C to +125°C

Standby current: <1µA (standby mode)

Driver/receiver count: 1/1

Product Applications

• Motor drivers

• Factory automation and control

• Grid infrastructure

• Building automation

• HVAC systems

• Video surveillance

• Process analysis

• Wireless infrastructure
