The AD9746BCPZ is a dual-channel, 14-bit, 250 MSPS digital-to-analog converter (DAC). This device has high dynamic range and low noise and intermodulation distortion (IMD) characteristics, is suitable for direct frequency conversion transmission applications, and can seamlessly interface with analog orthogonal modulators such as ADL5370 ‌.

Key parameters

Digit number: 14

Digital-to-analog converter number: 2

Establishment time: -

Output type: Current - Unbuffered

Differential output: Yes

Data interface: Parallel

Reference types: External, Internal

Voltage - Power supply, simulation: 3.13V to 3.47V

Voltage - Power supply, figures: 1.7V - 1.9V, 3.13V - 3.47V

INL/DNL (LSB) : ±1, ±0.5

Architecture: Four-way switch

Operating temperature: -40°C to 85°C

Package/Shell: 72-LFCSP

Installation type: Surface mount type

Application field

The AD9746BCPZ is suitable for a variety of wireless communication and instrumentation applications, including but not limited to:

Youdaoplaceholder0 Wireless infrastructure ‌ : WCDMA, CDMA2000, TD-SCDMA, WiMAX.

Youdaoplaceholder0 Broadband communication ‌ : LMDS/MMDS, point-to-point communication.

Youdaoplaceholder0 Instruments and meters ‌ : RF signal generator, arbitrary waveform generator ‌.
