The TPA3100D2PHP is a 20 W (per channel) high-efficiency Class D audio power amplifier for driving bridged stereo speakers. The TPA3100D2PHP can drive stereo speakers down to 4 W. The TPA3100D2PHP is up to 92% efficient, eliminating the need for an external heatsink when playing music.

The gain of the amplifier is controlled by two gain select pins. The gain selection range is 20, 26, 32 and 36 dB.

The outputs feature an auto-recovery function and monitor outputs that are fully protected against ground shorts, VCC shorts, and output-to-output shorts.

TPA3100D2PHP Product Attributes

Manufacturer: Texas Instruments

Product Category: Audio Amplifiers

Output Type: 2-Channel Stereo

Class: Class-D

Output Power: 21.8 W

THD + noise: 0.11 %

Package / Case: HTQFP-48

Audio - Load Impedance: 8 Ohms

Supply voltage - min: 10 V

Supply voltage - max: 26 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C

Mounting Style: SMD/SMT

Series: TPA3100D2

Description/Function: Speaker

Dual Supply Voltage: 12 V, 15 V, 18 V, 24 V

Gain: 36 dB

Height: 1 mm

Input Type: Analog

Length: 7 mm

Maximum dual supply voltage: 26 V

Minimum dual supply voltage: 10 V

Humidity sensitivity: Yes

Number of channels: 2 Channel

Operating supply current: 18 mA

Operating supply voltage: 12 V, 15 V, 18 V, 24 V

Output signal type: Differential

Pd-Power dissipation: 5 W

TPA3100D2PHP Product Applications

Televisions
