Service Telephone:86-755-83294757
Trade Name:LDO Linear Regulators
Brand:ADI
Particular Year:22+
Package:LFCSP-8
Delivery Date:New and Original
Stock: 6000pcs
The ADM7171ACPZ-1.8 is a CMOS, low dropout (LDO) linear regulator that operates from a 2.3 V to 6.5 V supply and provides up to 1 A of output current. This high output current LDO is ideal for regulating high performance analogue and mixed-signal circuits operating from 6 V to as low as 1.2 V supply rails. The device's advanced proprietary architecture provides high supply rejection ratio and low noise, and requires only a small 4.7 μF ceramic output capacitor to achieve excellent voltage and load transient response. Load transient response is typically 1.5 μs (for 1 mA to 500 mA load steps).
Available in an 8-pin, 3 mm × 3 mm LFCSP package, the ADM7171ACPZ-1.8 is not only a very compact solution, but also offers excellent thermal performance for applications requiring up to 1 A output current in a low profile and small footprint.
ADM7171ACPZ-1.8 Features
Input voltage range: 2.3 V to 6.5 V
Maximum load current: 1 A
Low noise: 5 μV rms at 100 Hz to 100 kHz, independent of output voltage
Fast transient response: 1.5 μs at 1 mA to 500 mA load step-over
60 dB PSRR at 100 kHz
Low dropout voltage: 42 mV at 500 mA load, VOUT = 3 V
Initial accuracy: -0.5% (min), +1% (max)
Line, load, and temperature accuracy: ±1.5 %
Quiescent current at no load IGND = 0.7 mA
Low shutdown current: 0.25 μA at VIN = 5 V
Stable operation with small 4.7 μF ceramic-type output capacitors
Adjustable and fixed output voltage options: 1.2 V to 5.0 V
Adjustable output from 1.2 V to VIN - VDO
Precision enable
Adjustable soft-start
8-pin 3 mm × 3 mm LFCSP package
ADM7171ACPZ-1.8 Applications
Voltage regulation for noise-sensitive applications: ADC and DAC circuits, precision amplifiers, PLL/VCOs, and clock ICs
Communications and infrastructure
Healthcare
Industrial and instrumentation
