NCV33202VDR2G op-amps provides rail-to-rail operation on both the input and output. The inputs can be driven as high as 200mV beyond the supply rails without phase reversal on the outputs, and the output can swing within 50 mV of each rail. This rail-to-rail operation enables the user to make full use of the supply voltage range available. It is designed to work at very low supply voltages ( +/- 0.9 V) yet can operate with a supply of up to +12V and ground. Output current boosting techniques provide a high output current capability while keeping the drain current of the amplifier to a minimum. Also, the combination of low noise and distortion with a high slew rate and drive capability make this an ideal amplifier for audio applications.

Specification Of NCV33202VDR2G

Number of Channels:2 Channel

GBP - Gain Bandwidth Product:2.2 MHz

SR - Slew Rate:1 V/us

Vos - Input Offset Voltage:14 mV

Ib - Input Bias Current:200 nA

Supply Voltage - Max:12 V, +/- 6 V

Supply Voltage - Min:1.8 V, +/- 900 mV

Operating Supply Current:1.8 mA

Output Current per Channel:80 mA

CMRR - Common Mode Rejection Ratio:60 dB

en - Input Voltage Noise Density:25 nV/sqrt Hz

Minimum Operating Temperature:- 55 C

Maximum Operating Temperature:+ 125 C

Dual Supply Voltage:+/- 3 V, +/- 5 V

Height:1.5 mm

In - Input Noise Current Density:0.8 pA/sqrt Hz

Length:5 mm

Maximum Dual Supply Voltage:+/- 6 V

Minimum Dual Supply Voltage:+/- 900 mV

Operating Supply Voltage:1.8 V to 12 V, +/- 900 mV to +/- 6 V

PSRR - Power Supply Rejection Ratio:66.02 dB

Voltage Gain dB:109.54 dB

Width:4 mm

Unit Weight:540 mg

Features Of NCV33202VDR2G

Low Voltage, Single Supply Operation (+1.8 V and Ground to +12 V and Ground)

Input Voltage Range Includes both Supply Rails

Output Voltage Swings within 50 mV of both Rails

No Phase Reversal on the Output for Over-driven Input Signals

High Output Current (ISC = 80 mA, Typ)

Low Supply Current (ID = 0.9 mA, Typ)

600 W Output Drive Capability

Extended Operating Temperature Ranges (-40° to +105°C and -55° to +125°C)

Typical Gain Bandwidth Product = 2.2 MHz
