Trade Name:DC-DC Converter
Brand:TI
Particular Year:23+
Package:SOT-5X3-8
Delivery Date:New and Original
Stock: 4000pcs
The TPS628501QDRLRQ1 is an automotive-grade, high-efficiency synchronous step-down DC/DC converter in a SOT-5X3-8 package for automotive electronics applications such as ADAS (Advanced Driver Assistance Systems), infotainment systems, body control modules and more.
TPS628501QDRLRQ1 Features
Wide input voltage range: 2.7V ~ 6V input for automotive battery-powered systems.
Adjustable output voltage: 0.6V ~ 5.5V adjustable to meet different load requirements.
High efficiency and low power consumption:
1A continuous output current (up to 2A peak), quiescent current only 17µA, optimised standby power consumption.
1.8MHz ~ 4MHz adjustable switching frequency, support PWM/PFM automatic switching, improve light load efficiency.
Automotive grade reliability:
AEC-Q100 certified, operating temperature range -40°C ~ 150°C (TJ) for harsh environments.
Low EMI design, optional pseudo-random spread spectrum (PRSS) to reduce electromagnetic interference.
Intelligent protection features:
Precise ENABLE control with support for under voltage lockout (UVLO) and power sequencing.
Foldback overcurrent protection to ensure safe system operation.
TPS628501QDRLRQ1 Typical Applications
Automotive electronics:
ADAS camera, radar sensor power supply.
In-vehicle infotainment (IVI), T-Box power management.
Industrial control:
Low-power FPGA, MCU power solutions.
Industrial automation equipment (PLC, HMI).
Consumer Electronics:
