PSoC™ 4 is a scalable and reconfigurable platform architecture for a family of programmable embedded system controllers with an Arm® Cortex®-M0+ CPU. It combines programmable and reconfigurable analog and digital blocks. PSoC™ 4100S Max is a member of the PSoC™ 4 platform architecture. It is a combination of a microcon troller with standard communication and timing peripherals, a capacitive sensing system with best-in-class performance, programmable general-purpose continuous-time analog blocks, and programmable connectivity.

Feature Of CY8C4149AZQ-S595

32-bit MCU subsystem

48-MHz Arm Cortex-M0+ CPU with single-cycle multiply

Up to 384 KB of flash with Read Accelerator

Up to32KB of SRAM

16-channel DMA engine

Programmable analog

Two opamps with reconfigurable high-drive external and high-bandwidth internal drive and Comparator modes and ADC input buffering capability. Opamps can operate in Deep Sleep low-power mode.

12-bit 1-Msps SAR ADC with differential and single-ended modes, and Channel Sequencer with signal averaging

Temperature sensor built into SAR ADC

Two low-power comparators that operate in Deep Sleep low-power mode

Programmable digital

Programmable Smart I/O logic blocks allowing Boolean operations to be performed on port inputs and outputs

Low-power 1.71-V to 5.5-V operation

Deep Sleep mode with operational analog and 3.7-µA digital system current

Capacitive sensing

Multi-sensing converter (MSC) provides best-in-class signal-to-noise ratio (SNR) (>5:1) and liquid tolerance for capacitive sensing

Infineon-supplied software middleware makes capacitive sensing design easy

Automatic hardware tuning (SmartSense)

Two MSC converters are provided

Autonomous channel scanning without CPU assistance

LCD Drive capability

LCD segment drive capability on GPIOs

I2S master transmitter

Cryptographic block

AES, SHA, TRNG, PRNG, and CRC functions

Serial communication

Five independent run- time reconfigurable serial communication blocks (SCBs) with re- configurable 12C, SPI,or UART functionality. High-speed I2C support is provided.

• 1.Is the inventory and price seen on the platform accurate?

  A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.

• 2.Are all our products genuine?

  A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.

• 3.Can you provide the qualification certificate of the original factory or agent?

  A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.

• 4.Can I make an inquiry through the company's website?

  A: You can inquire through the website, or by phone and email.

• 5.When can I deliver the goods after placing an order? How long will it take to get there?

  A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.

• 6.Can the company issue an invoice?

  A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
