SC32F5864LL1G is a high-performance microcontroller (MCU) manufactured by Hangzhou Silan Microelectronics Co., Ltd. (Silan Microelectronics). Based on the ARM Cortex-M0 core, it is specifically designed for motor control and digital power applications.

SC32F5864LL1G Features

High-performance core: Utilises the ARM Cortex-M0 core with a maximum operating frequency of 72MHz.

Extensive I/O Ports: Supports up to 48 I/O ports with programmable pull-up/pull-down, open-drain output mode, digital input filtering, and input inversion.

Enhanced PWM and ADC: Integrated enhanced PWM and ADC with a sampling rate of 1Msps.

Multiple Drive Capabilities: Features programmable two-stage drive capability.

External interrupt inputs: All I/O ports can function as external interrupt inputs, supporting both edge-triggered and level-triggered operation.

Low-power design: Optimised for low power consumption, suitable for battery-powered devices.

SC32F5864LL1G Specifications

Package Type: 48-LQFP (7x7)

Operating Voltage: VDD = 1.8V to 3.6V

Operating Temperature Range: -40°C to +85°C

Storage Capacity: Flash memory capacity of 64KB

RAM Capacity: SRAM capacity of 8KB

Interfaces: Supports multiple communication interfaces including SPI, I2C, UART

Applications

The SC32F5864LL1G is suitable for the following application scenarios:

Motor Control: For controlling various motors, such as stepper motors and DC motors.

Digital Power: For digital power management.

Industrial Automation: For industrial automation equipment.

Automotive Electronics: For automotive electronic systems.
