The LMX2491RTWR device is a low-noise 6.4GHz wideband Δ-Σ fractional N PLL with ramp/linear frequency modulation generation function. It consists of a phase-frequency detector, a programmable charge pump and a high-frequency input suitable for an external VCO. The LMX2491RTWR widely supports various flexible ramp functions, including FSK, PSK, and up to 8 configurable segmented linear FM modulation profiles. This device features precise PLL resolution and rapid ramp function, with a phase detector rate as high as 200MHz.

Basic parameters

The main parameters of LMX2491RTWR include:

Type: PLL

Circuit quantity: 1 Circuit

Maximum input frequency: 6.4 GHz

Minimum input frequency: 500 MHz

Output frequency range: 200 MHz

Power supply voltage - Maximum: 3.45V

Power supply voltage - minimum: 3.15V

Technology: Si

Minimum operating temperature: -40 ° C

Maximum operating temperature: + 85 ° C

Installation style: SMD/SMT

Package/Box: WQFN-24

The LMX2491RTWR is widely used in the following fields:

Frequency Modulated Continuous Wave (FMCW) radar

Military radar

Microwave return stroke

Testing and measurement

Satellite communication

Wireless infrastructure

Sampling clocks suitable for high-speed analog-to-digital converters/digital-to-analog converters (ADC/DAC)
