The ADF5356BCPZ, when used in combination with an external loop filter and an external reference frequency, enables a fractional N division or integer N division phase locked loop (PLL) frequency synthesizer. The wideband microwave VCO design allows operation in the frequency range of 6.8 GHz to 13.6 GHz at a single radio frequency (RF) output. A series of dividers at the other frequency output allows operation in the frequency range of 53.125 MHz to 6800 MHz.

The ADF5356BCPZ features an integrated VCO with a base output frequency range of 3400 MHz to 6800 MHz. In addition, VCO frequencies can be divided by connecting to 1, 2, 4, 8, 16, 32, or 64 circuits, so users can generate RF output frequencies as low as 53.125 MHz. For applications that require isolation, you can mute the RF output stage. The mute function can be controlled by pin or software.

The ADF5356BCPZ has the following main features:

RF output frequency range: 53.125 MHz to 13,600 MHz

Background noise integer channel: −227 dBc/Hz

Background noise decimal channel: −225 dBc/Hz

Integrated RMS jitter (1 kHz to 20 MHz) : 97 fs at 6 GHz output

Fractional N division synthesizer and integer N division synthesizer

Compatible with ADF5355 pin

High resolution 52-bit module

The phase frequency detector (PFD) operates at 125 MHz

Reference input frequency up to 600 MHz

Frequency locking is maintained in the range −40°C to +85°C

Low phase noise, Voltage Controlled Oscillator (VCO)

Programmable 1, 2, 4, 8, 16, 32 or 64 crossover output

Analog and digital power supply: 3.3V

Charge pump and VCO power supply: 5.0V (typical)

Logical compatibility: 1.8V

Programmable output power level

RF output mute function

ADIsimPLL design tool support
