The TLV49641M is an integrated Hall-effect switch designed for high-precision applications with excellent supply voltage capability, operating temperature range and magnetic threshold temperature stability.

It is well suited for a variety of position detection applications. With a supply voltage range from 3.0 V to 32 V, it has an overvoltage capability of up to 42 V (e.g., load sag) and requires no external resistors, making it ideal for automotive and industrial applications.

TLV49641M Features

3.0 V to 32 V operating supply voltage

Use of unregulated power supplies

Reverse polarity protection (-18 V)

Overvoltage capability up to 42 V without external resistors

Output overcurrent and overtemperature protection

Active error compensation

High magnetic threshold stability

Low jitter (0.35 μs typical)

High ESD performance

TLV49641M Advantages

Position detection

Automotive

Position detection in automotive and industrial applications

TLV49641M Specifications

Operating voltage: 3.0V to 5.5V

Operating temperature range: -40°C to +125°C

Package form factor: PG-TO92S

Applications: Consumer applications such as brushless DC motors, home power-off automation, power tools and gardening equipment, on/off detection, etc.
