The LIS3MDLTR is an ultra-low-power, high-performance 3-axis magnetometer with user-selectable full-scale ranges of ±4/±8/±12/±16 Gauss.

The self-test function allows users to verify the sensor's functionality in the final application.

When configured, the device can generate interrupt signals for magnetic field detection.

The LIS3MDLTR includes an I²C serial bus interface supporting standard mode and fast mode (100 kHz and 400 kHz), as well as multiple SPI serial standard interfaces.

The LIS3MDLTR is housed in a slim, compact plastic grid array (LGA) package, ensuring reliable operation over a wider temperature range (-40°C to +85°C).

LIS3MDLTR Features

Wide power supply voltage range: 1.9 V to 3.6 V

Independent IO power supply (1.8 V)

±4/±8/±12/±16 Gauss selectable magnetometer full scale

Continuous and single conversion modes

16-bit data output

Interrupt generator

Self-test function

I²C/SPI digital output interface

Power-saving mode/low-power mode

Compliant with ECOPACK and RoHS standards

LIS3MDLTR Product Attributes

Product Type: Trigger Interface Hall Effect/Magnetic Sensor

Operating Power Current: 270 uA

Operating Point Minimum/Maximum: ±4 G, ±8 G, ±12 G, ±16 G

Operating Power Voltage: 3 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

Mounting Style:    SMD/SMT

Package/Enclosure:    LGA-12

Series:    LIS3MDL

Supply Voltage - Maximum:    3.6 V

Supply Voltage - Minimum:    1.9 V

LIS3MDLTR Applications

• Magnetometer

• Compass
